Transport Monitoring

Connect piezometers and multi-point piezometers from all the major geotechnical sensor manufacturers. Use 1-channel or 5-channel Vibrating Wire data loggers to transmit data from any number of sensor configurations. Water level sensors can be connected through Analog or Digital Data Loggers.

Assess soil water tension and moisture with a tensiometer and a granular matrix sensor both connected to an Analog Data Logger. Additionally, measure volumetric water content with a soil moisture sensor connected to a Piconode. You can also connect the Digital Logger to one or a chain of digital tensiometers.

In-place inclinometers are positioned at fixed locations in the inclinometer borehole allowing continuous monitoring. Connect Shape Arrays and IPIs and wirelessly transmit data using the Digital Data Logger or the broadband ThreadX3 for longer chains.

Up to 200 segments of Shape Array using the Digital Logger and up to 300 segments using the ThreadX3.

Use cost-efficient GNSS sensors connected to a ThreadX3 to accurately monitor ground movements and land deformation in vast areas such as tailings dams, open-pit mines and their surrounding areas, regions affected by subsidence and decommissioned mines.

Complement your geotechnical monitoring with a total station connected to a ThreadX3 for accurate movement detection.

Leverage the power of Worldsensing’s 3-in-1 LaserTilt90 wireless sensor to monitor convergence across entrance ramps, tunnels, galleries, and any underground excavations. The LaserTilt90 may be easily relocated along the convergence cross sections up to the excavation front or until the measured relative displacements are stabilized when the required frequency of measurements is reduced. It can also be used when permanent monitoring is required.

Loadsensing G7 Tiltmeter offers a cost-effective way to monitor cant and twist in rail tracks, particularly in geohazard-prone areas. With G7’s trigger-mode monitoring, a secondary low-power accelerometer detects movements such as train passages and activates the main sensor to capture inclination data. This approach minimizes power use and data load while ensuring continuous, reliable oversight, with all results processed in CMT.

When rapid detection is necessary for real-time decision-making, use G7 Tiltmeters event detection operational mode. It offers less than 2 seconds of latency for movement detection. Paired with in-field cameras connected through Thread X3, they form a complete Early Warning System for end-to-end solution for effective risk management.

Monitor static deflections of piles, piers, and decks using Tilt-XHP. Enhance data robustness with a 3-in-1 Laser Tiltmeter, which includes distance laser measurements to a reference point in the monitoring process.

Attach VW Strain Gauges to the steel arch supported by arc welding them directly to the steel arch to achieve long-term strain measurements of the structural element. Connect the gauges to the Vibrating Wire 5-channel data logger. Additionally, it is possible to embed VW Strain Gauges in the shotcrete to measure strains within the tunnel lining.

Crack meters available in the market can be readily connected to a Vibrating Wire 1-channel data logger or the Piconode to monitor movement across surface cracks.

Monitor the pot bearing pressure and displacement through pressure sensors, extensometers or crackmeters. Control the joint expansions and contractions wirelessly connecting these sensors to Analog, Digital or Vibrating Wire data loggers.

Monitor the impact of industrial activities on surrounding infrastructure with Worldsensing’s Vibration Meter, designed to operate in compliance with industry standards for building integrity (DIN4150-3 and BS7385-2).

Compatibility with major weather transmitter manufacturers via digital interface. Monitor precipitation, air temperature and other weather parameters using a weather transmitter connected to a Digital logger or ThreadX3. Multiple configurations readily available to stream the right data to your information systems.

Monitor the impact of vibrations created by industrial activities on people’s comfort with Worldsensing’s Vibration Meter, designed to operate in compliance with industry standards (ISO 2631-2).
